Radius
Need to balance value and performance in your next commercial zero-turn lawn mower? Exmark has you covered with the Radius line of mowers. Select from the Radius E-Series, Radius S-Series, and Radius X-Series. This lineup of commercial, professional-grade lawn mowers offers legendary durability with a wide range of mower deck sizes. Select from cutting widths from 48 to 60 inches with all models delivering the Exmark signature maneuverability with our zero-turn technology.
Mowing large lots? The Radius commercial zero-turn mowers will get the job done right and quickly. Select the right amount of power for your needs, with Radius mowers offering options in horsepower ranging from a 20.5 horsepower engine in the S-Series to a 31-horsepower engine on the X-Series.
Exmark’s exclusive UltraCut decks are featured on Radius models. Every UltraCut cutting deck features Exmark’s exclusive maintenance-free, sealed-bearing spindle assemblies for increased durability and reduced downtime, combined with zero maintenance.
With a fully welded frame built from 2x3-inch frame tubes, the Radius design places major components including the engine, hydro drive system and fuel tank lower in the frame. The lower center of gravity and better mass centralization results in increased traction and stability, with improved handling.
Our patented height of cut adjustment system is user friendly and allows the operator to quickly and accurately select height of cut from the operator seat.
Radius S- and X-Series models feature an adjustable full-suspension operator seat, with three inches of suspension and an EVC stretch foam base for superior all day mowing comfort.
The floor pan and belt shields remove easily without tools, making it easier to access the belts and top of the cutting deck for maintenance. Plus, a standard welded jack receiver on the Radius frame enables easier service of the underside of the deck when combined with the optional jack.
Radius X-Series models feature upgraded caster assemblies featuring maintenance-free tapered caster pivot bearings, with cast steel caster forks and large, semi-pneumatic caster tires.
Radius Specs
| Product | Power | Deck Size | Deck | Fuel Capacity | Transmission | Ground Speed | Acres Per Hour | Cutting Height | Seat | Front Casters | Drive Tires | Warranty |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Radius E-Series
|
24.5HP Exmark 708 V-Twin or 24HP Kohler 7000 Series KT735
|
48" |
UltraCut Series 3
|
7.0gal
|
ZT-2800
|
8.0mph
|
3.1 |
1.5" to 5.0" in 0.25" increments
|
18" Commercial High Back
|
13x6.5-6 Pneumatic
|
22x9.5-12
|
4-Year or 500 Hours, Limited
|
| 52" | 3.35 | |||||||||||
| 60" |
ZT-3100
|
3.87 | 22x10.5-12 | |||||||||
|
Radius S-Series
|
20.5HP Kawasaki FX651V V-Twin | 48" |
9.0mph
|
3.48 |
20" Premium Full Adjustable Seat Suspension
|
23x9.5-12
|
4-Year or 750 Hours, Limited
|
|||||
| 22HP Kawasaki FX691V V-Twin | 52" | 3.77 | ||||||||||
| 23.5HP Kawasaki FX730V V-Twin | 60" | 4.35 | 23x10.5-12 | |||||||||
|
Radius X-Series
|
25.5HP Kawasaki FX801V V-Twin | 52" |
UltraCut Series 4
|
ZT-3400
|
10.0mph
|
4.83
|
13x6.5-6 Semi-Pneumatic
|
24x9.5-12 |
4-Year or 1,000 Hours, Limited
|
|||
| 31HP Kawasaki FX921V V-Twn | 60" | 24x12.0-12 |
